MATERIALS


PA12 WHITE PA12 BLACK PA12 FR PA11 BLACK TPU88A BLACK

PA12 WHITE

INFINAM PA 6002 P is a fine powder, created specifically for additive manufacturing applications, is distinguished by its outstanding strength and softness. This powder is ideal for both the production of individual units and mass production of parts.

PA12 WHITE DATASHEET




BENEFITS

  • Easy to process

  • High process stability

  • Excellent powder flow properties

  • Excellent mechanical properties

  • Excellent recyclability

  • Good chemical resistance

  • Suitable for skin contact

APPLICATIONS

  • Manufacturing of electronic housing

  • Custom parts

  • Prototypes

  • Anatomical model

  • Industrial components

  • Automotive components

PROPERTIES

  • Tensile strength up-to 50 MPa

  • Melting Point: 187°C

  • Elongation up to 16%

  • HDT B ISO 75-2:  161°C@0.46MPa

  • HDT A ISO 75-2:  58°C@1.8MPa

  • Can be dyed to other colors.

  • Biocompatible, Skin Contact, Food Contact

PA12 BLACK

INFINAM PA 6003 P is a fine powder, created specifically for additive manufacturing applications, is distinguished by its outstanding strength and softness. This powder is ideal for both the production of individual units and mass production of parts.

PA12 BLACK DATASHEET




BENEFITS

  • Easy to process

  • High process stability

  • Excellent surface resolution and feature detail

  • Excellent mechanical properties

  • Excellent recyclability

  • Good chemical resistance

  • Good energy absorption over a wide wave length range

  • Suitable for skin contact

APPLICATIONS

  • Electronic housing

  • Control panels

  • Aesthetic components with PA12 properties

  • Prototypes

  • Anatomical model

  • Industrial components

  • Automotive components

PROPERTIES

  • Tensile strength up-to 50 MPa

  • Melting Point: 187°C

  • Elongation up to 16%

  • HDT B ISO 75-2:  161°C@0.46MPa

  • HDT A ISO 75-2:  58°C@1.8MPa

  • Natural black

  • Biocompatible, Skin Contact, Food Contact

PA12 FR

INFINAM PA 6004 P is a fine powder of natural colour, specifically designed for the production of fireproof parts. It is suitable for the production of functional prototypes, the production of single units as well as series parts.

PA12 FR DATASHEET




BENEFITS

  • Powder for flame retardant 3D print parts

  • High process stability

  • Excellent surface resolution and feature detail

  • Excellent mechanical properties

  • Good chemical resistance

  • Suitable for skin contact

APPLICATIONS

  • Components requiring high fire resistance

  • Fire-resistant electronic housing

  • Prototypes

  • Mechanical parts

  • Industrial components

  • Components used in the chemical industry

  • Automotive components

PROPERTIES

  • Tensile strength up-to 46 MPa

  • Melting Point: 185°C

  • Elongation up to 4%

  • HDT B ISO 75-2:  161°C@0.46MPa

  • HDT A ISO 75-2:  84°C@1.8MPa

  • Biocompatible, Skin Contact, Food Contact

  • Flammability UL 94

PA11 BLACK

Ultrasint® PA11 is a bio-derived powder material for advanced applications where toughness matters. PA 11 BLACK is the perfect choice for the production of parts that need to withstand high mechanical stress, such as hinges, interior automobile parts, or external fender structures.

PA11 BLACK DATASHEET




BENEFITS

  • Exceptionally high toughness

  • Does not splinter in most crash cases

  • Suitable for skin contact

  • Color: Black

APPLICATIONS

  • Components requiring good mechanical strength

  • Gears and hinges

  • Electronic housing

  • Industrial components

  • Prototypes

  • Bumper components

PROPERTIES

  • Tensile strength up-to 45 MPa

  • Elongation at break: 42%

  • HDT B ISO 75-2: 176°C@0.46MPa

  • HDT A ISO 75-2:  76°C@1.8MPa

  • Biocompatible, Skin Contact, Food Contact

TPU88A BLACK

Ultrasint® TPU 88A black is a multi-purpose thermoplastic polyurethane (TPU) powder that enables TPU for desktop machines. High shock absorption, energy return and flexibility are just some of the benefits of this material.

TPU88A BLACK DATASHEET




BENEFITS

  • High elasticity, rebound, and resistance to fatigue

  • Also suitable for desktop machines

  • UV and fatigue resistant

  • High recycling rate of 80%

  • Color: Black

APPLICATIONS

  • Flexible components

  • Seals

  • Vibration damping components

  • Cushioning parts

  • Footwear

  • Grippers

PROPERTIES

  • Tensile strength: 8.0 MPa

  • Elongation at break: 360%

  • Hardness shore: 86-88 A

  • Rebound resilience: 63 %

  • Young’s modulus: 85 MPa
